473 nm激光器

  Wavelength

473nm

  Spatial Mode

near TEM00

  Output Power

>200mW,

  Operation Mode

CW or Modulation

  Linewidth

<1 nm

  Polarization

Linear

  Beam Spot Shape

Circular, aspect ratio<1.1:1

  Pointing Stability

<0.05 mrad

  Beam Diameter(1/e2)

3 mm

  Beam Divergence

1.5  mrad

  Beam Height from Base

29mm

  Power Stability*

<±5% per 2 hrs

  Temperature Stabilizing

TEC

  Warm Up Time

<5 minutes

  Beam Quality (M2)

<2

  Optimum Operating Temperature

20~30oc

  Storage Temperature

10~50oC

  MTTF**

10,000 hrs

  Dimensions

155(L)x77(W)x60(H) mm

Power Supply

A. OEM type

LSR-PS-NI: 100(L)x70(W)x55(H)mm3

AC/DC PSU: 85~265V 50/60Hz input

C. Adjustable Lab type

LSR-PS-FA: 178(W)x197(D)x84(H) mm3

Modulation

0~30khz Analog or TTL
